WS-315 Model Gantry Shear with 3150kn Max Cutting Force and 800mm Blade Length for Scrap Metal Processing
무료샘플과 쿠폰을 위해 나와 연락하세요.
왓츠앱:0086 18588475571
위챗: 0086 18588475571
스카이프: sales10@aixton.com
만약 당신이 어떠한 관심도 가지면, 우리가 24 시간 온라인 도움말을 제공합니다.
x제품 상세 정보
| 모델번호 | WS-315 | 최대 절단력 | 3150KN |
|---|---|---|---|
| 블레이드 길이 | 800mm | 생산 속도 | 3-5t/h |
| 힘 | 60kW | 공칭 힘 | 400 톤 |
| 피구동형 | 유압 | 최대 전단 길이 | 1600MM |
| 전압 | 21.5MPA | 자동등급 | 오토매틱 |
| 절삭홈 높이 | 300/420mm | 생산능력 | 5 세트/월 |
| 최대 절삭력 (WS-400) | 4000KN | 블레이드 길이(WS-400) | 1000mm |
| 전원(WS-400) | 74kW | ||
| 강조하다 | WS-315 Model Gantry Shear,3150kn Max Cutting Force Scrap Metal Shear,800mm Blade Length Horizontal Metal Shear |
||
제품 설명
WS-315 Horizontal Scrap Metal Shear Machine
The WS Horizontal Metal Shear is designed for economical scrap processing with easy operation and flexible transportation via roll on/roll off system. Various models are available to suit different operational requirements.
Key Features
- Horizontal structure allows for manual or automatic feeding with conveyor
- PLC control with push-button operation ensures safety and reliability
- High output capacity for efficient scrap processing
- Works with manual belting (HPM series)
Technical Specifications
Product Name:
WS Horizontal Metal Shear
Condition:
New
Application:
Scrap metal
Nominal Force:
400Ton
Driven Type:
Hydraulic
Max. Length To Shear:
1600mm
Voltage:
21.5Mpa, Customized
Color:
Customized
Automatic Grade:
Automatic
Commercial Terms
Minimum Order Quantity:
1 Set
Price:
Negotiable
Payment Terms:
30% T/T In Advance
Supply Ability:
5 sets/month
Delivery Time:
As per your requirement
Packaging Details:
Seaworthy packing
After-sales Service:
Engineers available for overseas service
Model Specifications
| Model | Max Cutting Force (KN) | Blade Length (mm) | Shear Height (mm) | Production Rate (t/h) | Power (KW) |
|---|---|---|---|---|---|
| WS-400 | 4000 | 1000 | 300/420 | 4-7 | 74 |
| WS-500 | 5000 | 1400/1600 | 300/420 | 6-9 | 90 |
| WS-630 | 6300 | 1400/1600 | 300/420 | 8-15 | 135 |
| WS-800 | 8000 | 1600 | 420/500 | 12-18 | 180 |
| WS-1000 | 10000 | 1600/2100 | 420/500 | 15-25 | 225 |
