WS-630H High Speed Scrap Metal Shear with 1400mm Blade 5-6 Cuts/min and PLC Control
제품 상세 정보
| 모델 | WS-630H | 최대 절단력 | 630톤 |
|---|---|---|---|
| 블레이드 길이 | 1400mm | 절삭홈 높이 | 300/420 밀리미터 |
| 절단 속도 | 5-6회/분 | 처리능력 | 12-18 톤/시간 |
| 총 전력 | 132kW | 펌프 유형 | A4V250 x 2 듀얼 독립형 |
| 제어 시스템 | PLC + 원격 제어 | 냉각 | 듀얼 강제 공기 52P x 2 |
| 강조하다 | Dual Pump High Speed Shear,1400mm Blade Scrap Cutter,PLC Container Metal Shear |
||
제품 설명
WS-630H High Speed Scrap Metal Shear 1400mm Blade Dual Pump 5-6 Cuts/min PLC Control Container Type
WS-630H High Speed Dual Pump Scrap Metal Shear
The WS-630H is an advanced high-speed container type scrap metal shear equipped with a dual independent pump hydraulic system, delivering up to 5-6 cutting cycles per minute — double the speed of conventional models. Designed for high-volume scrap processing yards and steel recycling facilities, this machine maximizes throughput while maintaining precise cutting control.
Key Features
- Dual Independent Pump System: Two A4V250 pumps working in parallel for faster oil delivery and reduced cycle time
- High-Speed Cutting: 5-6 cuts per minute vs. typical 2-3, significantly boosting daily processing capacity
- Reinforced Blade Design: 4-edge reversible 1400mm blades made of Cr12MoV alloy steel with heat treatment
- PLC Auto Control: Touch screen interface with remote control capability for unmanned operation
- Enhanced Cooling: Dual forced air coolers (52P x 2) for sustained high-speed operation without overheating
- Container Design: Roll-on/roll-off system for flexible yard-to-yard transportation
Applications
Suitable for cold shearing of round steel, square steel, channel steel, I-beam, steel plates, pipes, and various scrap metal structural parts in large-scale recycling facilities.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | WS-630H |
| Max Cutting Force | 630 Tons |
| Blade Length | 1400 mm |
| Shear Height | 300/420 mm |
| Cutting Speed | 5-6 times/min |
| Processing Capacity | 12-18 tons/hour |
| Total Power | 132 KW (66 KW x 2 Motors) |
| Pump Configuration | A4V250 x 2 (Dual Independent) |
| Hydraulic System Pressure | ≤ 31.5 MPa |
| Control System | PLC + Remote Control |
| Cooling System | Dual Forced Air Cooler (52P x 2) |
| Power Supply | 380V/3P 50Hz (Customizable) |
| Blade Material | Cr12MoV Alloy Steel |
| Machine Weight | 38 Tons |
Our Service
- 24/7 online technical support
- One year warranty with lifelong maintenance
- Free spare parts for quality issues within warranty
- On-site installation and training available
- OEM & ODM services available upon request
Contact us today for a customized quote and technical consultation.
