WS-1000G Gantry Heavy Duty Scrap Metal Shear with 1000 Ton Cutting Force and 2100mm Blade for Industrial Scrap Processing
제품 상세 정보
| 모델 | WS-1000G | 구조 유형 | 갠트리 프레임 |
|---|---|---|---|
| 최대 절단력 | 1000 톤 | 블레이드 길이 | 2100 mm |
| 절삭홈 높이 | 420/500 밀리미터 | 맥스 강판 | 두께 80mm |
| 맥스 라운드 스틸 | φ150 mm | 총 전력 | 275 kw |
| 제어 시스템 | PLC 터치스크린 + 리모트 | 냉각 | 수냉식 튜브 시스템 |
| 강조하다 | Gantry Frame Metal Shear,2100mm Heavy Duty Cutter,1000 Ton Scrap Processor |
||
제품 설명
WS-1000G Gantry Heavy Duty Scrap Metal Shear 2100mm Blade 1000 Ton Cutting Force Steel Plate Processing
WS-1000G Gantry Type Heavy Duty Scrap Metal Shear
The WS-1000G represents a departure from conventional container-type shears, featuring a robust gantry frame structure engineered for extreme-duty scrap processing. With 1000 tons of cutting force and a massive 2100mm blade, this machine handles oversized scrap that standard shears cannot process — including heavy structural steel, railway tracks, thick ship plates, and industrial machinery remnants.
Key Advantages of Gantry Design
- Superior Structural Rigidity: Heavy steel gantry frame withstands extreme lateral forces without deformation
- 2100mm Extended Blade: 30% longer than standard container models for processing oversized materials
- 1000 Ton Cutting Force: Capable of shearing steel plates up to 80mm thick and round steel up to Φ150mm
- Large Feed Opening: 3500mm x 2500mm hopper accommodates bulky scrap without pre-processing
- Twin Shear Cylinder Design: YG500/320 cylinders with 5000kN x 2 force for balanced cutting
- Industrial Grade Hydraulics: Heavy-duty Rexroth-type variable displacement pumps for continuous operation
Applications
Designed for heavy industrial applications including ship dismantling yards, large-scale steel mills, railway scrap processing, bridge demolition recycling, and heavy machinery disposal facilities.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | WS-1000G |
| Structure Type | Gantry Frame |
| Max Cutting Force | 1000 Tons |
| Blade Length | 2100 mm |
| Shear Height | 420/500 mm |
| Cutting Speed | 2-3 times/min (load) |
| Processing Capacity | 15-25 tons/hour |
| Total Power | 275 KW |
| Shear Cylinder | YG500/320 x 2 (5000kN each) |
| Press Cylinder | YG320/250 (2000kN) |
| Max Steel Plate Thickness | 80 mm |
| Max Round Steel Diameter | Φ150 mm |
| Feed Opening | 3500 x 2500 mm |
| Hydraulic System Pressure | ≤ 31.5 MPa |
| Control System | PLC Touch Screen + Remote Control |
| Cooling System | Water Cooling with Tube Cooler |
| Power Supply | 380V/3P 50Hz (Customizable) |
| Machine Weight | 68 Tons |
| Overall Dimensions | 15000 x 3500 x 4200 mm |
Our Service
- 24/7 online technical support with remote diagnostics
- One year comprehensive warranty with lifelong maintenance
- Free spare parts for manufacturing defects within warranty
- On-site installation, commissioning, and operator training available
- Custom engineering solutions for specific scrap processing requirements
Contact our engineering team for a detailed proposal and site assessment.
